Description:
Laminated glass is consists of two or more plies of glass which are bonded together with interlayers to form a permanent bond by heat and pressure . The inter layers work to support and hold the glass to create a strong, uniformed layer even when broken. Typical inter layers are PVB, Sentry Glass Plus and so on. The monolithic glass comes in different thicknesses, from 3mm to 22mm. It could also be coated glass, like low e coating glass, reflective coating glass, veedas easy cleaning glass and so on to reach different colors, performances of laminated glass. In order to reach the best sound isolation, energy saving glass effect, it could be further structuring into laminated insulating glass.
Laminated glass, because of its high safety and energy saving performances, is widely applying to window, walls, furniture, balustrades, etc. One of the typical application is hurricane resistance glass for instance.
Specification:
Glass Type | Laminated Glass |
Single Glass Thickness | 3mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm, 19mm, 22mm, 25mm etc |
Double Glass Thickness | 6.38mm, 8.38mm, 10.38mm, 12.38mm, 16.38mm,6.76mm, 8.76mm, 10.76mm, 12.76mm, 16.76mm, 20.76mm, 24.76mm.7.14mm, 9.14mm, 11.14mm, 13.14mm, 17.14mm, 21.14mm, 25.14mm, 31.14, 39.14mm7.52mm, 9.52mm, 11.52mm, 13.52mm, 17.52mm, 21.52mm, 25.52mm, 32.28, 40.28mm, etc |
Multi Glass | 2 layer laminated glass, 3 layers laminated glass, etc |
Film Thickness | 0.38mm, 0.76mm, 1.14mm, 1.52mm, 2.28mm, 3.04mm, etc |
Glass Color | Clear Laminated Glass, Low Iron Laminated Glass, Super White Laminated Glass, Super Clear Laminated Glass, Extra White Laminated Glass, Starphire Laminated Glass, Optiwhite Laminated Glass, Euro Grey Laminated Glass, Dark Grey Laminated Glass, Crystal Grey Laminated Glass, Brown Laminated Glass, Bronze Laminated Glass, Ocean Blue Laminated Glass, Ford Blue Laminated Glass, Dark Blue Laminated Glass, Color laminated glass, etc. |
Interlayer Color | Clear, Milky White,Translucent White, Colored Blue, Dark Grey,Light Green, Bronze, etc |
Film Type | PVB, SGP, EVA, etc |
Size | Customized |
Max size | 18000mm L*3660mm H |
Trade Terms | FOB, CIF, etc |
Lead Time | Generally 2-4 weeks, depend on order quantity. |
Shape | Flat or Curved laminated glass |
Edge Work | Flat Edge, Seamed Edge, Polished Edge, Bevelled edge, Flat Polished Edge, Round Edge,Arrised edge, C Shape, etc. upon your request. |
Irregular Shape | Rectangular, Round, Oval, Trapezoid, Parallel, etc. All edges can be bright polished. |
Hole & Notch | Countersunk holes, round holes, bell-mouth holes, simple notch, mickey ears cutouts, etc. The edge of hole and notch can be polished by CNC |
Terms of Payment | 30% down payment before production, 70% balance TT at shipment, L/C |
MOQ | To be discussed |
|
